9T Performance

JE Pistons - VR6 Forged Pistons Set

JE Pistons - VR6 Forged Pistons Set

Regular price $1,232.66 USD
Regular price Sale price $1,232.66 USD
Sale Sold out
Engine Size
Compression Ratio
Cylinder Bore

JE Pistons - VR6 Forged Pistons Set

As the leader in forged racing pistons, JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import and sport compact applications. Engineered, forged and machined 100% in the USA, JE Pistons are designed for each specific engine and racing application to provide the ultimate combination of durability and performance. From drift track to drag strip, JE Pistons’ performance is proven in victory lane time and time again. Equip your engine with the best in forged pistons.

  • Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
  • Designed specifically for each engine and use application to provide optimized performance durability
  • Proprietary Forged Side Relief (FSR) forging design minimizes friction and power loss with reduced skirt width and saves additional weight with a shorter wrist pin
  • Skirt coating (depending on application) reduces friction and wear on piston skirts and cylinder walls while simultaneously reducing operating noise
  • Accumulator groove (depending on application) helps reduce pressure from combustion gases, reducing ring fluttering and improving ring seal for consistent power
  • Includes high-quality wrist pins, locks, and JE Pro Seal premium piston rings
  • Made 100% in the USA

Specifications:

Piston Series JE Pistons
Cylinder Head VR6
Piston Head Type Flat
Piston Material 2618
Piston Quantity 6
Forging Type Round
Ring Set Included Yes
Top Compression Ring Thickness 0.0400 IN
Second Compression Ring Thickness 0.0480 IN
Oil Ring Thickness 0.111 IN
Wrist Pin Outer Diameter 0.787 IN
Wrist Pin Length 2.250 IN
Wrist Pin Wall Thickness 0.180 IN
